FSP MPF0000500GP UPS-tartozék

The FSP MPF0000500GP is a white UPS accessory designed to provide network and serial management capabilities for compatible uninterruptible power supply systems. It supports SNMP management protocols and offers an RS-232 interface for direct serial connection. The module is compact and lightweight, intended to enable remote monitoring and control of UPS devices while occupying minimal space within a rack or enclosure.

Advantages

The unit combines SNMP protocol support with an RS-232 port to deliver both network-based and local serial management options. Its 12 V input and 0.5 A operating current ensure compatibility with standard UPS control power supplies while keeping power consumption low. The small footprint and white enclosure make it straightforward to integrate into existing installations without significant rearrangement.

Suitable for

• Remote UPS monitoring and management via SNMP
• Local serial configuration or diagnostics through RS-232
• Integration into compact rack or cabinet installations
• System administrators needing network-accessible UPS status and alerts

Key specifications

• Input voltage: 12 V
• Operating current: 0.5 A
• Interfaces: SNMP (network management), RS-232 (serial)
• Colour: White
• Dimensions (W × D × H): 78 mm × 80 mm × 28.5 mm
• Weight: 0.068 kg

How to use

Install the accessory in the UPS according to the UPS manufacturer's instructions, ensuring the 12 V supply is properly connected and the unit is secured within the chassis or mounting location. For network management, configure the SNMP settings using the UPS management interface or the accessory's web/management console if available, and add the device to your network monitoring system. For local access, connect a serial cable to the RS-232 port and use a terminal application to perform configuration or diagnostics. Verify communication and test alerting or shutdown procedures after installation.

Recommendations

Use shielded cabling for RS-232 connections in electrically noisy environments, assign a fixed IP address or reserve a DHCP lease for reliable SNMP access, and follow the UPS vendor's guidelines for firmware compatibility and secure network configuration.
