InLine EV töltőkábel 11 kW Type 2, 3 fázisú, 7,5 m

The InLine EV car charging cable is designed for charging electric and hybrid vehicles with the Type 2 plug standard used in Europe. It supports charging up to 11 kW (3-phase, 16 A) and measures 7.5 m in length, making it suitable for connecting vehicles to public charging stations or wallboxes. The cable is manufactured to be robust and durable for varied environments, with protection against dust and water and connector caps to prevent soiling and moisture.

Advantages

The cable provides a standardized Type 2 connection on both ends, supports 3-phase charging up to 11 kW and a maximum current of 16 A, and offers a 7.5 m reach for flexible vehicle positioning. It is lightweight (approx. 2.6 kg) for easier handling and storage. Protective caps on the connectors and housing protection against dust and water increase reliability in outdoor and indoor use.

Suitable for

• Charging electric cars and plug-in hybrids with Type 2 sockets
• Connecting to public AC charging stations
• Using with residential wallboxes that accept Type 2 cables

Key specifications

• Connector type: Type 2 — both ends
• Maximum power: 11 kW (3-phase)
• Maximum current: 16 A
• Length: 7.5 m
• Weight: approx. 2.6 kg
• Protection: dust and water resistant; connector protective caps included
• Brand / MPN / EAN: InLine / 16277I / 4043718316434

How to use

Ensure your vehicle accepts a Type 2 connection and that the charging station or wallbox supports 11 kW or the required current. Uncap the connectors, plug one end into the vehicle inlet and the other into the charging station or wallbox socket until each connector locks in place. Monitor the vehicle and charger indications during the charging process. After charging completes, unlock and remove the connectors, replace the protective caps, and store the cable in a dry place.

Recommendations

Use the cable within its specified current and power limits (maximum 16 A / 11 kW). Avoid placing the cable where it can be driven over or exposed to sharp edges. Regularly inspect connectors and protective caps for damage and clean them if contaminated. Store the cable out of direct sunlight and extreme temperatures to prolong service life.
