LevelOne Gigabit IEEE802.3bt PoE-splitter

The LevelOne POS-5000 Gigabit High Power PoE Splitter separates a networked PoE signal into distinct power and Gigabit data outputs. It enables running high-speed PoE cabling over long distances and then splitting that signal to power non-PoE devices while maintaining Gigabit network connectivity. Active versions are available with 12V or 24V DC outputs. The compact splitter includes short-circuit protection to protect connected equipment.

Advantages

The PoE splitter reduces installation complexity by removing the need for nearby power outlets at device locations. It supports Gigabit throughput while delivering power and data separately, allowing use with Wi‑Fi access points, PTZ IP cameras and other non-PoE equipment. Available output voltages increase compatibility with different devices.

Key specifications

• Model: LevelOne POS-5000
• Function: PoE splitter — separates power and Gigabit data
• Data rate: Gigabit Ethernet
• Output voltages: selectable active models 12V or 24V DC
• Protection: short-circuit protection

How to use

Connect the PoE input from a PoE switch or injector to the splitter's input port. Connect the splitter's data output to the device's Ethernet port and the power output to the device's DC power jack. Choose the active model with the required output voltage (12V or 24V) to match the powered device. Ensure proper cable terminations and test connectivity and power delivery after installation.
