DIGITUS OnLine UPS modul 2000VA / 2000W

DIGITUS OnLine UPS modul 2000VA / 2000W
DIGITUS OnLine UPS modul 2000VA / 2000W
DIGITUS OnLine UPS modul 2000VA / 2000W
DIGITUS OnLine UPS modul 2000VA / 2000W
DIGITUS OnLine UPS modul 2000VA / 2000W
DIGITUS OnLine UPS modul 2000VA / 2000W
DIGITUS OnLine UPS modul 2000VA / 2000W
DIGITUS OnLine UPS modul 2000VA / 2000W
DIGITUS OnLine UPS modul 2000VA / 2000W
DIGITUS OnLine UPS modul 2000VA / 2000W
191 569 Ft
The OnLine UPS is an ideal backup solution for your demanding power requirements and offers high reliability in various industrial applications.- High power factor (1.0), a higher active power enables more connected loads, which saves space and reduces costs.- High efficiency in online mode, higher ... Bővebben
Készlet 1 Termékkód 300091 Márka DIGITUS Modell DN-170095 Garancia 2 év
KategóriaOnline szünetmentes tápegységek (UPS)

Szállítás és visszaküldés

Várható kiszállítás november 6., péntek
Részletes csomagkövető rendszerünk segítségével folyamatosan tájékoztatjuk
Fizetési lehetőségek
BankkártyaVisaMastercardPayPalApple PayGoogle PayBanki átutalás

Leírás

The OnLine UPS is an ideal backup solution for your demanding power requirements and offers high reliability in various industrial applications.

- High power factor (1.0), a higher active power enables more connected loads, which saves space and reduces costs.
- High efficiency in online mode, higher efficiency means optimized energy management and lower heat dissipation, resulting in energy savings and improved reliability.
- User-friendly LCD screen provides insight into UPS status for easy installation, configuration and operation.
- Compact rack/tower design optimizes the installation space in the rack and enables flexible installation.
- Minimize device downtime with hot-swappable, user-replaceable battery modules that can be replaced during operation.
- External battery modules allow the runtime to be extended.
- High number of outlets (8 x C13) for optimum power distribution to the consumers.
- Various communication interfaces (RS232/USB, parallel port, SNMP slot) enable remote monitoring of the system.
- Automatic battery self-test and fan speed control increase the service life of the components.
- The REPO function (Remote Emergency Power Off) switches the UPS off in the event of an emergency. If an emergency occurs, the REPO switch turns off the rectifier and the inverter and immediately stops the power supply to the load. The UPS stops charging.

The DIGITUS® OnLine UPS is a double-conversion UPS solution that offers first-class power failure protection and continuous power generation in a compact and flexible system. The single-phase UPS operates with high energy efficiency and is ideal for protecting critical infrastructure in both centralized and edge network applications. Scalable runtime options with matching external battery cabinets provide additional flexibility when a longer uninterruptible power supply is required. The user-friendly LCD display and network management capability, including configuration, make this system easy to install and maintain. With market-leading efficiency and unity power factor, the UPS meets your critical application requirements.

Főbb jellemzők
  • Online double conversion system (VFI-SS-111)
  • Input: IEC60320 C20 socket, 208/220/230/240 Vac
  • Output: 8 x IEC60320 C13, max. 10A per socket outlet
  • Nominal system power: 2000 VA / 2000 W, power factor 1.0
  • AC-AC (online VFI) efficiency: 93 %, ECO mode efficiency: 98 %.
  • Internal battery pack can be replaced during operation.
  • Battery: Valve-protected, non-spillable lead-acid battery
  • Battery quantity: 4 x 12V x 9.0 Ah
  • Charging: 4 hours to 90% capacity after full discharge
  • Network connection: Optional SNMP/Webcard (part number DN-170100) enables the UPS to be monitored remotely.
  • Local communication ports: USB, RS-232 (serial), SNMP card (optional), relay card (optional)
  • Emergency Power-off (EPO) contact for switching off the UPS in an emergency
  • Maximum operating temperature: 0 - 40 °C
  • Storage temperature: -25 - 55 °C
  • Relative humidity: 20 - 90% non-condensing
  • Operating altitude: < 1500 m
  • Product dimensions WxDxH (mm): 440 (19") x 460 x 86.5 (2U)
  • Product weight: 19.5 kg
  • Shipping dimensions WxDxH (mm): 560 x 590 x 200
  • Shipping weight: 23.7 kg
  • Safety standards: IEC/EN62040-1,IEC/EN60950-1
  • EMC standards: IEC/EN62040-2,IEC61000-4-2,IEC61000-4-3,IEC61000-4-4, IEC61000-4-5,IEC61000-4-6,IEC61000-4-8
  • Optionally available: 19" UPS mounting kit (profile rails), article number DN-170109
  • IP protection class: IP21
  • Heat dissipation: 614 BTU/h
  • Noise level in online mode: approx. 50 dB(A) at a distance of 1 m (may vary slightly depending on load and ambient temperature).

Műszaki adatok

Műszaki adatok
AC kimenetek száma
8 AC outlet(s)
Akkumulátor kapacitása
9 Ah
Akkumulátor töltési ideje (90%)
4 h
Aljzattípusok
C13 coupler
Áramforrás típusa
AC
Beépített ventilátor
Igen
Bemeneti üzemi feszültség (max.)
240 V
Bemeneti üzemi feszültség (min.)
208 V
Csomag magassága
200 mm
Csomag szélessége
555 mm
Csomag térfogata
66705.5 cm³
Csomag tömege
22.9 kg
Csomagolás mélysége
595 mm
Elem feszültsége
12 V
Ethernet LAN (RJ-45) portok
2
Formfaktor
Rackbe szerelhető
Hálózati dugó
C20 coupler
Hatékonyság
93%
Hatékonyság (ECO mód)
98%
Hűtés típusa
Aktív
Kézikönyv
Igen
Kijelző típusa
LCD
Kimeneti teljesítmény
2000 W
Kimeneti teljesítménykapacitás
1.5 kVA
Levehető tápkábel
Igen
Magasság
86.5 mm
Maximális áramerősség
10 A
Mellékelt kábelek
RS-232, USB cable
Mélység
460 mm
Méret (hüvelyk)
48.3 cm (19")
Rack-szerelőkészlet
Igen
Relatív páratartalom tároláskor (H-H)
20 - 90%
Soros interfész
RS-232
Soros portok száma
1
Származási ország
Kína
Szélesség
440 mm
Támogatott elemek száma
4
Tárolási hőmérséklet (T-T)
-25 - 55 °C
Teljesítménytényező
1
Termék színe
Fekete
Tömeg
19.5 kg
UK vámtarifakód
85044085
UPS-topológia
Dupla konverziós (online)
USB-csatlakozó típusa
USB Type-B
USB-port
Igen
Üzemi hőmérséklet (T-T)
0 - 40 °C
Üzemi magasság
0 - 1500 m
Üzemi relatív páratartalom (H-H)
20 - 90%
Vészleállító (EPO) csatlakozó
Igen
